ACTi - ACM-3701(2.4mm) - 1.3MP f3.6mm Indoor Fixed Dome with
Product Overview
The ACTi ACM-3701 is a 1.3MP fixed dome camera designed for legacy indoor and outdoor surveillance applications. It uses a progressive scan CMOS sensor, a fixed 3.6mm lens, and IP66 weatherproof construction for protected deployment.
Key Configuration
Discontinued fixed dome camera; indoor/outdoor application environment; 1.3MP maximum resolution with progressive scan CMOS image sensor; 1/3 in. sensor size; fixed 3.6mm lens with IP66 weatherproof construction.
Key Features
• 1.3MP resolution supports legacy surveillance imaging
• Progressive scan CMOS sensor supports digital video capture
• Fixed 3.6mm lens provides consistent scene coverage
• DSP-based configurable color to B/W switch supports image mode control
• IP66 weatherproof rating supports indoor or outdoor deployment
Technical Context
The camera uses a 1/3 in. progressive scan CMOS sensor with standard low-light sensitivity. Minimum illumination is listed as color 0.5 lux at F1.0 and black-and-white 0.5 lux at F1.0, while the electronic shutter supports 1/30-1/1000 second in manual mode at 60 Hz and 1/5-1/15000 second in auto mode.
Installation Notes
Because the ACM-3701 is discontinued, availability and replacement planning should be confirmed before use in new projects. The IP66 weatherproof rating supports installation where protection from dust and water ingress is required.
| Product Profile | |
| Product Type | Fixed Dome |
| Application Environment | Indoor/Outdoor |
| Maximum Resolution | 1.3MP |
| Image Sensor | Progressive Scan CMOS |
| Sensor Size | 1/3 " |
| Day / Night | No |
| Low Light Sensitivity | Standard |
| Minimum Illumination | Color: 0.5 lux at F1.0 (30 IRE, 2400 K); B/W: 0.5 lux at F1.0 (30 IRE, 2400 K) |
| Mechanical IR Cut Filter | No |
| Color to B/W Switch | DSP based switch, configurable |
| Electronic Shutter | 1/30-1/1000 second (manual mode, 60 Hz), 1/5-1/15000 second (auto mode) |
| S/N Ratio | 44 dB |
| Lens | |
| Focal Length | Fixed focal, f3.6mm |
| Aperture | F1.8 |
| Iris | Fixed iris |
| Focus | Fixed focus |
| Lens Mount | Board mount |
| Horizontal Viewing Angle | 72.3° |
| Viewing Angle Adjustment | Pan: ±20°, Tilt: 0°-90°, Rotation: ±15° |
| Video | |
| Compression | MPEG-4 SP, MJPEG |
| Maximum Frame Rate vs. Resolution | 8 fps at 1280 x 1024 10 fps at 1280 x 720 30 fps at 640 x 480 |
| Bit Rate | 28Kbps - 3Mbps |
| Bit Rate Mode | Constant, Variable |
| Multi-Streaming | Simultaneous dual streams based on two configurations |
| Digital Noise Reduction | No |
| Image Orientation | Flip, Mirror |
| Image Enhancement | White Balance, Brightness, Saturation, Contrast, Sharpness, Automatic gain control (AGC), Automatic exposure, Flickerless |
| Privacy Mask | 1 configurable regions |
| Server-based Analytics | Object Line Counting, People Counting, Face Detection, Object Based Motion Detection, Tamper, Object Line Crossing Detection, Object Enter Area Detection, Missing Object Detection, Unattended Object Detection, Smoke Detection, Heat Map, Dwell Time, People Queue Detection, (Require PC-based or standalone IVS or ALPR Server. Contact ACTi support for recommendations on how to maximize analytical accuracy) |
| Network | |
| Network Protocol & Service | IP, TCP, UDP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, NTP, RTP, RTSP, SMTP, FTP, IGMP, ICMP, ARP, Bonjour, UPnP, ToS, SNMP, IEEE 802.1X |
| Ethernet Port | 1 x RJ-45 connector |
| Security | IP address filtering, HTTPS encryption, Password protected user level, IEEE 802.1X network access control |
| Event | |
| Event Trigger | Video motion detection (3 regions) |
| Event Response | Notify control center, Change camera settings, Command other devices, E-mail notification with snapshots, Upload video or snapshot to FTP server, Activate external device through digital output |
| Integration | |
| Unified Solution | Fully compatible with ACTi software |
| Software Development Kit | Yes |
| Web Browser | IE 8.0 or newer |
| General | |
| Power Source | PoE Class 3 (IEEE802.3af) |
| Power Consumption | 2.4 W (PoE) |
| Weight | 220g (0.48lb) |
| Dimensions | (Ø x H): 100mm x 50mm (3.94" x 1.97") |
| Environmental Casing | Weatherproof (IP66), Vandal proof up to 722.66 KgF (328.09 lbF) |
| Mount Type | Surface, Gang Box, Pendant, Converter for NPT Standard Mounts, Wall Mount |
| Starting Temperature | -20°C ~ 50°C (-4°F ~ 122°F) |
| Operating Temperature | -20°C ~ 50°C (-4°F ~ 122°F) |
| Operating Humidity | 10% - 85% RH, non-condensing |
| Approvals | CE, FCC, UL (for optional PoE injector) |
| Warranty | 1 Year(s). For extended warranty offering, see http://www.acti.com/support/warranty |
