CyberPower - CP2000PFCRM2U - PFC Sinewave 2U Rackmount UPS

Product Overview

The CyberPower CP2000PFCRM2U is a PFC Sinewave rackmount UPS designed to provide battery backup, surge protection, and EMI/RFI filtration for security systems, audio/visual equipment, and network devices. It delivers sine wave output for active PFC power source compatibility and includes AVR technology to stabilize minor voltage fluctuations without using battery power.

Key Configuration

Model: CP2000PFCRM2U | Product Type: PFC Sinewave rackmount UPS | Output Type: Sine wave | Topology: Line interactive | Rack Format: 2U short-depth rackmount | Chassis Depth: 10.8 inches | Rack Compatibility: Fits racks as shallow as 14 inches | Display: Multifunction color LCD | Remote Management: Optional Remote Network Management Card or Cloud Monitoring Card | Warranty: 3 years including batteries | Connected Equipment Guarantee: $500,000

Key Features

 · Provides battery backup for controlled shutdown during utility power failure

 · Sine wave output supports sensitive electronics and active PFC equipment

 · Surge protection helps shield connected devices from AC power spikes

 · Automatic Voltage Regulation stabilizes minor voltage fluctuations without switching to battery mode

 · EMI/RFI noise filtering helps maintain clean power for connected equipment

 · Short-depth 2U rackmount design supports shallow rack installations

 · Multifunction color LCD shows real-time battery and power condition alerts

 · Data line protection helps guard Ethernet-connected equipment from surge damage

 · ENERGY STAR certified design supports efficient operation

 · GreenPower UPS bypass design reduces energy use, heat, and operating noise

Technical Context

The CP2000PFCRM2U uses line interactive UPS topology with an autotransformer to regulate brownouts and overvoltage conditions before battery power is required. Its sine wave output provides low total harmonic distortion, reduced electrical noise, and improved signal integrity for sensitive AV, networking, and security equipment.

Installation Notes

The 10.8-inch short-depth chassis is optimized for shallow rack environments where standard UPS systems may not fit. Remote monitoring can be added with an optional Remote Network Management Card or Cloud Monitoring Card, and PowerPanel Business software is available for UPS monitoring and backup power management.
