CyberPower - CSB1206 - Essential Surge Protector

Part number:
Price:

Product Overview

The CyberPower CSB1206 is a 12-outlet surge protector designed to protect home and office electronics from power surges and electrical spikes. It provides 3600 joules of surge protection and includes a 6-foot power cord for flexible placement around computers, peripherals, routers, cameras, and other sensitive devices.



Key Configuration

Model: CSB1206 | Product Type: Surge Protector | Outlets: 12 | Surge Protection Rating: 3600 joules | Power Cord Length: 6 ft | Outlet Design: Wide spaced outlets | Protection Technology: Metal Oxide Varistor technology | Warranty: Limited Lifetime Warranty | Connected Equipment Guarantee: Included



Key Features

 · Provides essential surge protection for home and office electronics

 · Offers 3600 joules of protection against power surges and spikes

 · Includes twelve outlets for connecting multiple devices

 · Wide spaced outlets help accommodate larger power adapters without blocking adjacent outlets

 · Metal Oxide Varistor technology redirects surge energy through the ground circuit

 · 6-foot power cord supports flexible installation and device placement

 · Connected Equipment Guarantee covers properly connected equipment damaged by a power surge

 · Limited Lifetime Warranty covers defects in materials and workmanship



Technical Context

The CSB1206 uses MOV-based surge suppression to allow normal electrical current to pass while redirecting excess voltage away from connected electronics during surge events. This helps protect sensitive equipment from damage caused by storms, grid fluctuations, and AC power spikes.



Installation Notes

The 6-foot power cord gives the surge protector practical placement flexibility for desks, workstations, entertainment areas, and office equipment clusters. The package includes the surge protector.

Input
Circuit Breaker15 A
Cord Length6 ft (1.8 m)
Input Plug TypeNEMA 5-15P
Maximum Input Current15A
Plug Style45° Offset Right
Output
Outlet Type12 – NEMA 5-15R
Outlets – Total12
Surge Protection & Filtering
Attenuation32 dB
Clamping Voltage800V (H-N, H-G, N-G)
EMI/RFI Filtration150 KHz
100 MHz
yes
Maximum Surge Current90000 A
Maximum Surge Current H-G30000 A
Maximum Surge Current H-N30000 A
Maximum Surge Current N-G30000 A
Maximum Surge Voltage6000
Surge Suppression (Joules)3600 J
Physical
ColorBlack
Form FactorStrip
Form Factors SupportedKeyhole (Wall Mount or Under-counter Installation)
Keyhole Mounting SlotsYes
Material of ConstructionPlastic
Dimensions
Physical Dimensions – (WxHxD) (cm)10.31 x 4.39 x 30.51 (cm)
Physical Dimensions – (WxHxD) (in)4.06 x 1.73 x 12.01 (in)
Physical Dimensions – (WxHxD) (mm)103 x 44 x 305 (mm)
Physical Weight (kg)0.72
Physical Weight (lb)1.59
Dimensions – Shipping
Shipping – Weight (kg)0.73
Shipping – Weight (lb)1.6
Shipping Dimensions – (WxHxD) (cm)36.51 x 6.35 x 17.78 (cm)
Shipping Dimensions – (WxHxD) (in)14.38 x 2.5 x 7.0 (in)
Shipping Dimensions – (WxHxD) (mm)365.13 x 63.5 x 177.8 (mm)
Certifications
EnvironmentalRoHS Compliant
SafetyETLus (UL1363 & UL1449 compliant)
DOE VI
NR Can
FCC
ICES-003
Warranty
CEG Amount$300000
Connected Equipment GuaranteeLifetime
Product WarrantyLimited Lifetime Warranty
