CyberPower - P205UC - Desktop Surge Protector
Product Overview
The CyberPower P205UC is a compact desktop surge protector power strip and charger designed to add power access and device charging to desks, tabletops, and other home or office areas. It combines two grounded AC outlets with USB-A and USB-C charging ports, providing surge protection and convenient charging in one small outlet extender.
Key Configuration
Model: P205UC | Product Type: Desktop Surge Protector Power Strip and Charger | AC Outlets: 2 grounded outlets | Surge Protection: 500J | USB Ports: 2 USB-A and 1 USB-C | USB-A Output: 2.4A charging power | USB-C Output: 15W | Warranty: One-year limited warranty
Key Features
· Expands one grounded outlet into two grounded AC outlets
· Provides 500J surge protection for connected electronics
· Includes two USB-A charging ports for tablets, smartphones, and mobile accessories
· Includes one 15W USB-C charging port for compatible USB-C devices
· Compact desktop design fits well on desks, tables, and home office surfaces
· Impact-resistant casing helps protect the unit and extend product life
· Combines AC power, USB charging, and surge protection in one outlet extender
Technical Context
The P205UC is designed for everyday electronics and mobile device charging where a standard wall outlet does not provide enough accessible connections. Its surge protection helps divert excess voltage away from connected devices during power spikes or AC surge events.
The USB-C port is rated at 15 watts and is not intended for laptop charging, making it better suited for phones, tablets, and smaller USB-powered accessories.
Installation Notes
The P205UC is intended for desktop, tabletop, and general indoor use where convenient access to AC outlets and USB charging is needed. The package includes one 2-outlet round surge protector with USB-A and USB-C charging ports.
| Input | |
| Cord Length | 5 ft (1.5 m) |
| Input Plug Type | NEMA 5-15P |
| Input Voltage | 125 VAC |
| Maximum Input Current | 15A |
| Plug Style | Right Angle – 45° Offset |
| Output | |
| Outlet Type | 2 – NEMA 5-15R |
| Outlets – Total | 2 |
| Output Voltage | 125 VAC |
| Output Watts – Continuous | 1875 W |
| USB Charge Port | Yes |
| USB Charge Port Amperage | 2.4 Amps (Shared) |
| USB Charge Port Quantity | 3 |
| USB Charge Port Standard | Type A and Type C |
| USB Charge Port Type | 2 Type A 1 Type C |
| USB Charge Port Voltage | 5 VDC |
| USB Charge Port Watts | 15 Watts |
| Surge Protection & Filtering | |
| Clamping Voltage | 800V (H-N) |
| EMI/RFI Filtration | 150 KHz |
| Maximum Surge Current | 15000 A |
| Maximum Surge Current H-N | 15000 A |
| Maximum Surge Voltage | 6000 V |
| Network Protection RJ45 | None |
| Response Time | <1 Nanosecond |
| Surge Suppression (Joules) | 500 J |
| Physical | |
| Color | White |
| Form Factors Supported | Horizontal Mount in Variety of Other Applications |
| Keyhole Mounting Slots | No |
| Material of Construction | Plastic |
| Dimensions | |
| Physical Dimensions – (WxHxD) (cm) | 11.0 x 3.51 x 11.0 (cm) |
| Physical Dimensions – (WxHxD) (in) | 4.33 x 1.38 x 4.33 (in) |
| Physical Dimensions – (WxHxD) (mm) | 110 x 35 x 110 (mm) |
| Physical Weight (kg) | 0.37 |
| Physical Weight (lb) | 0.81 |
| Dimensions – Shipping | |
| Shipping – Weight (kg) | 0.36 |
| Shipping – Weight (lb) | 0.8 |
| Shipping Dimensions – (WxHxD) (cm) | 12.38 x 17.78 x 8.26 (cm) |
| Shipping Dimensions – (WxHxD) (in) | 4.88 x 7.0 x 3.25 (in) |
| Shipping Dimensions – (WxHxD) (mm) | 123.83 x 177.8 x 82.55 (mm) |
| Certifications | |
| Environmental | RoHS Compliant |
| Safety | UL1449 4th Edition, UL 1310, FCC Part 15B, DOE VI |
| Warranty | |
| CEG Amount | $25000 |
| Connected Equipment Guarantee | Lifetime |
| Product Warranty | 1 Year Limited Warranty |
