Speco - H24HRLN4TB - 24 Channel Hybrid Recorder - 8 TVI + 8 Hybrid (TVI or IP) + 8 IP, NDAA, 4TB

Name: Speco - H24HRLN4TB - 24 Channel Hybrid Recorder - 8 TVI + 8 Hybrid (TVI or IP) + 8 IP, NDAA, 4TB
Brand: SPECO Technologies
SKU: H24HRLN4TB

Part number:

Price:

Dealers only

Add to Quote/Project Registration

Description Specifications Downloads

Product Overview

The H24HRLN4TB from Speco is a versatile 24 channel hybrid recorder, offering 8 TVI, 8 hybrid (TVI or IP), and 8 IP channels. With advanced features like 5MP support, H.265 compression, and extensive storage options, this recorder delivers high-quality performance and exceptional value for surveillance needs.

Key Configuration

Model: H24HRLN4TB

Key Features

• Supports up to 5MP: Captures high-definition video on all channels, ensuring clear and detailed footage for better surveillance.
• H.265 Compression: Efficiently stores up to 2x more data than H.264, optimizing storage use without sacrificing video quality.
• 2 SATA Ports: Provides ample storage with 4TB included, allowing for extensive video recording without frequent overwrites.
• eSATA Port: Extendable storage capabilities with an additional 8TB, accommodating growing surveillance needs.
• 4K HDMI & VGA Outputs: Supports multiple display options for flexibility in monitoring and playback.

Installation Notes

15" x 10.6" x 1.8" (380mm x 268mm x 45mm)

Specifications
NDAA	Compliant
Number Of Channels	24 Channel
Recording FPS (Per Channel)	7 FPS @ 3840 × 2160
Compression Method	H.265, H.264
Computer Connectivity	Windows PC
Mobile Platform	Android, Iphone; Speco Blue iOS®, Android™, SecureGuard® Client (Specification Sheet (H24HRLN column))
Mobile connectivity	Mobile Apps, Web Browser
Harddrive Size	4TB
Features	Audio Recording Capability, Free DDNS, Multi-Zone Video Motion Detection, Multiple User Authorization, PTZ Support, 4K Resolution
Smart Search	Highlighted color to display camera records in a certain period of time, different colors refer to different record events
Details
2 SATA Ports	Provides ample storage with 4TB included, allowing for extensive video recording without frequent overwrites.
System
OS	Embeded Linux
Video
Analog Input signal	HD-TVI, AHD, CVI, CVBS
Analog Only Input	BNC x16
Configurable Analog Inputs	8
IPC Only Input	8-CH*
Network Access & Transfer Bandwidth	64/192Mbps
Network Access Format	8MP/5MP/4MP/3MP/1080P/960P/720P@ 25/30fps
Output
Output	HDMIx1: 4Kx2K/1920x1080/1280x1024
Output	VGAx1: 1920x1080/1280/x1024/1024x768
Output	BNCx1: CVBS (used as the main or spot output)
Audio
Input	RCAx8
2-way Audio	Take up channel one audio input
Local Output	RCAx1
Record
Record Stream	Dual stream recording
Resolution	4K/5MP/4MP/1080P/720P/WD1
Frame Rate	Analog: 5MP@ 12fps (PAL/NTSC), 4MP/3MP@12fps/15FPS (PAL/NTSC), Under 4MP@ 25fps/30fps (PAL/NTSC) IP: 8MP and under@ 25/30fps (PAL/NTSC)
Bit Rate	32~78Mbps
Mode	Manual, schedule, motion, sensor, intelligence
Playback
Simultaneous Playback	Max 16-CH
Search Mode	EZ Search, museum search, time search, event search, bookmark search, snapshot search
Function	Play, pause, FF, FB, etc.
Alarm
Mode	Manual, sensor, motion, exception, intelligence
Input	16-CH local alarm input; Support IPC alarm input
Output	4-CH local alarm input; Support IPC alarm input
Linkage	Record, snapshot, preset, e-mail, pop-up window, etc.
Network
Interface	RJ45 10M/100M/100Mbps x 1
Protocol	TCP/IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, RTSP
Web Client	Multiple online users monitoring
Other Viewing Platforms	Apple TV® and Amazon Fire TV®
Storage
HDD	SATAx2, max 40TB per HDD
eSATA	eSATAx1 max 8TB
Export
Local	USB, USB mobile HDD
Network	Yes
Interface
USB	USB2.0x2
Remote Control	Yes
Dimensions
Power Supply	DC12V/4A
Power Consumption	≤30W(without HDD)
Dimensions(WxDxH)	15" x 10.6" x 1.8" (380mm x 268mm x 45mm)
