Speco - SP4AWETW - All-Weather Elite Series 4" Speakers With Transformers
Part number:
Price:
Product Overview
All-Weather Elite Series 4” Speakers With Transformers
Key Configuration
Model: SP4AWETW
Key Features
- • Rounded, stylish design.
- • Horizontal-swivel mounting bracket.
- • Weather-resistant design.
- • 70/25V selectable transformer.
- • 5 year warranty**Products are in compliance with NDAA Section 889 Part B Guidelines.
Installation Notes
6" (W) × 9.5" (H) × 6.5" (D)
| Full Specifications | |
| Woofer Size | 4 |
| Speaker Color | White |
| Speaker Specifications | |
| Model | SP4AWET/SP4AWETW |
| RMS Power | 25W |
| Max Power | 40W |
| Transformer Type | 70/25V (selectable) |
| Transformer Power Taps | 20W, 15W, 10W, 5W |
| Termination Type | Press terminal |
| Sensitivity (1W/1M) | 84dB |
| Maximum SPL (Pmax/1M) | 104dB |
| Driver Impedance | 8 Ohms |
| Magnet | 9 oz. ferrite |
| Frequency Response Range | 74Hz ~ 20kHz |
| Dispersion @ 1000Hz | 180° Conical |
| Drivers | 4" Mica/Polypropylene woofer 0.75" Silk tweeter |
| Speaker Dimensions | 6" (W) × 9.5" (H) × 6.5" (D) |
| Weight | 5.5lbs |
| Material | Body: High impact polystyrene Grille: Treated metal Bracket: Treated metal |
Name
Description
Size
Downloads
File
Specification
0.3mb
File
User Manual
0.1mb
