Speco - SPC15T - 8" Weatherproof PA Speaker with Transformer
Part number:
Price:
Product Overview
• Weather-resistant, aluminum construction • Includes mounting bracket • Rubber bell protector • Selectable 70/25V transformer dial • 2 year warranty *also available in 6.5" and 10.5" **Products are in compliance with NDAA Section 889 Part B Guidelines
Key Configuration
Model: SPC15T
Key Features
- • Manufactured to comply with RoHS standards.
Installation Notes
8.5” (Dia.) x 9” (D)
| Full Specifications | |
| Speaker Color | Gray |
| RMS Power | 15W |
| Max. Power | 30W |
| Transformer Type | 70/25V |
| Transformer Power Taps | 70V: 15W, 10W, 5W, 3W, 1W 25V: 15W, 10W, 3.7W, 1.9W, 1.3W, 0.6W, 0.4W, 0.1W |
| Termination Type | Wire strip |
| Sensitivity (1W/1M) | 105dB |
| Maximum SPL (Pmax/1m) | 117dB |
| Driver Impedance | 8 Ohms |
| Magnet | 4.9 oz. ferrite |
| Frequency Response Range | 450Hz ~ 15kHz |
| Dispersion@100Hz | 75º conical |
| Material | Aluminum |
| Color | Grey |
Name
Description
Size
Downloads
File
Specification
0.3mb
