Speco - VID2412CONV - CCTV Power Converter 24VAC into 12VDC 500mA Regulated Output
Part number:
Price:
Product Overview
Products are in compliance with NDAA Section 889 Part B Guidelines
Key Configuration
Model: VID2412CONV
Key Features
- • Converts 24VAC power signals to 12VDC.
- • AC24V to DC12V power converter with DC plug cable 500mA max.
- • For DC type cameras or video power sources conversion using AC24V for professional CCTV installation.
Installation Notes
1.1"(W) x 1"(H) x 2.5"(L) - not including cable and connector
| Full Specifications | |
| Output Voltage | 12VDC |
| Input Voltage | 24VAC |
| Output Current | 500mA |
| Input Power | AC15-26V; DC15-28V |
| Output Power | DC12V regulated |
| Material | ABS plastic |
| Cable | Input side: 15cm, 22AWG, 2 pin terminal block Output side: 15cm, 22AWG, DC Plug |
| Dimensions | 1.1"(W) x 1"(H) x 2.5"(L) - not including cable and connector |
| Weight | 0.9 oz. |
Name
Description
Size
Downloads
File
Specification
0.3mb
File
User Manual
0.2mb
