Wi-Tek - WI-AC50 V2 - Physical controller for Wi-Tek access points
Product Overview
WI-AC50V2 is a physical wireless controller for Wi-Tek access points, designed to manage and configure up to 50 APs in hotels, shopping malls, offices, and similar networks. It supports cloud and L3 management, automatic AP discovery, batch configuration, fast roaming, captive portal authentication, and RF optimization. The compact controller can be powered through 48V PoE input or a micro USB connection.
Key Configuration
Model: WI-AC50V2 | AP Management: Up to 50 access points | Interfaces: 2×10/100Mbps Ethernet ports, 1×USB 2.0, 1×micro USB, 1×2.4GHz wireless interface | Memory: 128MB RAM, 16MB Flash | Power: 48V PoE input or micro USB | Dimensions: 63 × 63 × 24mm
Key Features
- · Manages and configures up to 50 Wi-Tek access points
- · Two 10/100Mbps Ethernet ports, including one PoE input port
- · Supports 48V PoE input or micro USB power supply
- · Cloud management and L3 management support
- · Automatic AP discovery and batch configuration simplify network deployment
- · Fast roaming enables seamless transitions between access points
- · Captive portal supports local, web, RADIUS, and SMS authentication
- · 5GHz preferred band steering helps guide clients to the optimal band
- · Spectrum analysis and automatic channel selection support RF optimization
- · Supports remote AP updating, multi-SSID configuration, and access whitelists and blacklists
Technical Context
Fast roaming allows wireless clients to move between managed access points with minimal interruption. Band steering can direct compatible clients toward the 5GHz band, while spectrum analysis and automatic channel selection help reduce radio-frequency interference. Centralized batch configuration and remote updating simplify administration across multiple access points.
Installation Notes
The compact controller measures 63 × 63 × 24mm and is suitable for desktop or built-in mounting. It can be powered through the RJ45 PoE input using 48V PoE or through the micro USB port. Operating temperature is -40°C to 55°C with 5%-95% non-condensing humidity.
| General | |
| Model | WI-AC50V2 |
| Product Type | Physical controller for Wi-Tek access points |
| Maximum Managed Access Points | Up to 50 APs |
| Hardware | |
| CPU | 600 MHz |
| Memory | 128 MB RAM 16 MB Flash |
| Ethernet Interfaces | 2 × 10/100 Mbps Ethernet ports 1 port supports PoE input |
| USB Interface | 1 × USB 2.0 port, reserved |
| Power Interface | 1 × Micro USB port |
| Wireless Interface | 1 × 2.4 GHz wireless interface |
| Network and Management | |
| Network Access | Static IP, DHCP |
| Cloud Management | Free cloud management |
| Management Layer | Layer 3 management support |
| AP Management | Automatic AP discovery Batch configuration Control panel Multi-SSID management Remote AP updating Whitelisting and blacklisting |
| Features | |
| Fast Roaming | Roaming between APs without connection loss |
| Captive Portal | Local, web, RADIUS, and SMS authentication |
| Band Steering | 5 GHz preferred band steering |
| RF Optimization | Spectrum analysis and automatic channel selection |
| Power | |
| PoE Input | 48 V PoE input via RJ45 port |
| Alternative Power Supply | Micro USB power supply |
| Mechanical | |
| Installation | Desktop-mounted or built-in installation |
| Dimensions | 63 × 63 × 24 mm |
| Environmental | |
| Operating Temperature | -40 to 55 °C |
| Storage Temperature | -40 to 70 °C |
| Operating Humidity | 5% to 95%, non-condensing |
| Storage Humidity | 5% to 95%, non-condensing |
| Package Contents | |
| Included Items | WI-AC50 unit × 1 Ethernet cable × 1 Quick installation guide × 1 |
