Wi-Tek - WI-AP717MP V2 - AC1200M Indoor Wireless Mesh Wi-Fi Access Point

Product Overview

The Wi-Tek WI-AP717MP(V2) is an indoor-rated 802.11AC dual-band EasyMesh wireless access point designed for cloud-managed Wi-Fi coverage and PoE device connectivity. It provides 1200Mbps combined wireless speed, three Gigabit Ethernet PoE ports, one 802.3bt PoE input, two 802.3af/at PoE output ports, EasyMesh support, fast roaming, SD-LAN, and Cloud Web/App management.

Key Configuration

Model: WI-AP717MP(V2) | Product Type: Indoor EasyMesh Wireless Access Point | Wireless Standard: 802.11AC | Wireless Speed: 300Mbps at 2.4GHz + 867Mbps at 5GHz | Ethernet Ports: 3 x Gigabit Ethernet PoE | PoE Input: 1 x 802.3bt, 60W | PoE Output: 2 x 802.3af/at | Power Input: 48VDC-52VDC support | Mesh Support: EasyMesh | Network Features: Fast Roaming, SD-LAN | Management: Cloud Web and Cloud App

Key Features

 · Indoor-rated dual-band 802.11AC wireless access point

 · Supports 300Mbps wireless speed at 2.4GHz

 · Supports 867Mbps wireless speed at 5GHz

 · Provides three Gigabit Ethernet PoE ports

 · Supports one 802.3bt 60W PoE input

 · Supports two 802.3af/at PoE output ports

 · 48VDC-52VDC power input support provides flexible powering options

 · EasyMesh Connect design supports large-area wireless coverage

 · Fast roaming technology helps maintain smoother client handoff

 · SD-LAN technology supports flexible network deployment

 · Cloud Web and Cloud App management enable remote configuration and maintenance

Technical Context

The WI-AP717MP(V2) is intended for indoor wireless deployments where access point coverage, EasyMesh expansion, and downstream PoE device support are needed from a single unit. Its 802.3bt PoE input can power the access point while supporting two 802.3af/at PoE output ports for connected devices.

Cloud management, SD-LAN, EasyMesh, and fast roaming help simplify deployment across larger indoor spaces while improving wireless continuity for moving clients.

Installation Notes

The WI-AP717MP(V2) does not include a PoE injector, so a compatible PoE injector or PoE switch must be purchased separately if PoE power is not already available. EasyMesh devices can be networked only with devices that support the EasyMesh standard.
