Wi-Tek - WI-PCES326GF V2 - 1000Mbps Cloud Easy Smart PoE/ Ethernet Switch

Product Overview

This Wi-Tek 1000Mbps Cloud Easy Smart PoE/Ethernet Switch is designed for high-density managed Gigabit PoE access deployments that require fiber uplinks, cloud-based monitoring, remote configuration, and smart network protection features. It provides twenty-four 1000Mbps RJ45 PoE ports, two 1000Mbps SFP slots, IEEE 802.3af/at PoE output up to 30W per port, and a total PoE power budget of up to 382W.

Key Configuration

Product Type: 1000Mbps Cloud Easy Smart PoE/Ethernet Switch | PoE Ports: 24 x 1000Mbps RJ45 | SFP Slots: 2 x 1000Mbps | PoE Standard: IEEE 802.3af/at | PoE Output: Up to 30W on ports 1-24 | Total PoE Budget: Up to 382W | Network Features: Automatic Anti-Loop, Link Aggregation, QoS, DHCP Snooping | Camera Discovery: ONVIF Support | Management: Wi-Tek Cloud

Key Features

 · Provides twenty-four 1000Mbps RJ45 PoE ports for powered network devices

 · Includes two 1000Mbps SFP slots for fiber uplink connectivity

 · Ports 1-24 support IEEE 802.3af/at PoE output up to 30W

 · Total PoE power budget of up to 382W supports high-density PoE deployments

 · Port automatic anti-loop helps maintain network continuity

 · Alarm notifications support real-time maintenance

 · ONVIF support helps automatically identify connected IP cameras

 · Link aggregation helps increase network bandwidth and reliability

 · QoS support helps high-priority services operate normally

 · DHCP Snooping helps prevent unauthorized DHCP servers and improve IP allocation security

 · Wi-Tek Cloud management enables real-time monitoring and remote configuration

Technical Context

This switch is intended for managed Gigabit PoE access networks where many IP cameras, access points, or other PoE devices require power and data over Ethernet with fiber uplink capability. The two SFP slots provide flexible upstream connectivity for longer-distance fiber links or backbone integration.

Cloud management, ONVIF camera discovery, automatic anti-loop, link aggregation, QoS, DHCP Snooping, and alarm notifications help improve remote visibility, network reliability, service prioritization, and IP assignment security in surveillance and network edge deployments.

Installation Notes

This Cloud Easy Smart PoE/Ethernet switch is suitable for high-density Gigabit PoE access deployments requiring fiber uplinks and remote cloud management. PoE planning should account for the total 382W power budget and the 30W maximum output available on ports 1-24.
