Wi-Tek - WI-PCMS310GF-O (V2) - Cloud L2+ 1000Mbps Outdoor Waterproof PoE Switch

Product Overview

The Wi-Tek WI-PCMS310GF-O V2 is a Cloud L2+ managed outdoor waterproof PoE access switch designed for surveillance and network edge deployments in harsh environments. It provides eight Gigabit RJ45 PoE ports, two Gigabit SFP slots, high-power PoE++ support on ports 1-2, and Wi-Tek Cloud management for remote monitoring and configuration.

Key Configuration

Model: WI-PCMS310GF-O V2 | Product Type: Cloud L2+ Managed Outdoor Waterproof PoE Switch | PoE Ports: 8 x 1000 Mbps RJ45 | SFP Slots: 2 x 1000 Mbps | PoE Output: Ports 1-2 support 802.3af/at/bt up to 90W; ports 3-8 support 802.3af/at up to 30W | Total PoE Budget: Up to 115W | Protection Rating: IP65 | Management: Web, CLI, Telnet, SSH, SNMP, RMON, Wi-Tek Cloud

Key Features

 · Provides eight 1000 Mbps RJ45 PoE ports for IP cameras and network devices

 · Includes two 1000 Mbps SFP slots for fiber uplink connectivity

 · Ports 1-2 support high-power 802.3af/at/bt PoE++ output up to 90W

 · Ports 3-8 support 802.3af/at PoE output up to 30W

 · Total PoE power budget of up to 115W supports multiple powered devices

 · IP65 weatherproof and dustproof housing supports outdoor installation

 · Supports Web, CLI, Telnet, SSH, SNMP, and RMON management

 · Includes ACL, DoS Defend, storm control, DHCP Snooping, and other security policies

 · Port automatic anti-loop helps maintain network continuity

 · Alarm notifications support real-time maintenance and faster response

 · ONVIF support helps automatically identify connected IP cameras

 · Wi-Tek Cloud enables remote monitoring and configuration

Technical Context

This switch is built for outdoor surveillance networks where Gigabit PoE access, fiber uplinks, and centralized management are required. Its PoE++ support on the first two ports makes it suitable for higher-power devices, while the remaining PoE+ ports support standard IP cameras and other PoE endpoints.

L2+ management features such as ACL, DoS Defend, storm control, DHCP Snooping, SNMP, RMON, and CLI access provide stronger control over traffic, security, and maintenance compared with basic unmanaged or easy-smart switches.

Installation Notes

The WI-PCMS310GF-O V2 is suitable for outdoor wall, pole, or enclosure-based network deployments where IP65 protection and remote cloud management are needed. PoE load planning should account for the total 115W power budget and the higher 90W capability available only on ports 1-2.
