Wi-Tek - WI-PCMS310GF V2 - Cloud L2+ Managed PoE Switch

Product Overview

This Wi-Tek Cloud L2+ Managed PoE Switch is designed for PoE access and aggregation deployments that require high-density Gigabit PoE connectivity, fiber uplinks, combo ports, security controls, static routing, DHCP service, and cloud-based management. It provides twenty-four 1000Mbps PoE+ RJ45 ports, two 1000Mbps SFP slots, two 1000Mbps combo SFP ports, and a total PoE power budget of up to 397W.

Key Configuration

Product Type: Cloud L2+ Managed PoE Access/Aggregation Switch | PoE Ports: 24 x 1000Mbps RJ45 | SFP Slots: 2 x 1000Mbps | Combo SFP Ports: 2 x 1000Mbps | PoE Standard: IEEE 802.3af/at | PoE Output: Up to 30W on ports 1-24 | Total PoE Budget: Up to 397W | Routing: Static Routing | DHCP: DHCP Service | Security: ACL, DoS Defend, Storm Control, DHCP Snooping | Management: Web, CLI via Console Port/Telnet/SSH, SNMP, RMON, Cloud Management

Key Features

 · Provides twenty-four 1000Mbps PoE+ RJ45 ports for powered network devices

 · Includes two 1000Mbps SFP slots for fiber uplink connectivity

 · Includes two 1000Mbps combo SFP ports for flexible uplink options

 · Ports 1-24 support IEEE 802.3af/at PoE output up to 30W

 · Total PoE power budget of up to 397W supports high-density PoE deployments

 · Security policies include ACL, DoS Defend, storm control, and DHCP Snooping

 · Static Routing helps route internal traffic for more efficient network resource use

 · DHCP service helps assign IP addresses to connected devices

 · Supports Web, CLI, Console Port, Telnet, SSH, SNMP, and RMON management

 · Cloud management simplifies remote maintenance and administration

Technical Context

This switch is intended for managed PoE access and aggregation networks where many IP cameras, access points, or other powered devices need Gigabit connectivity. The combination of SFP and combo SFP ports provides flexible uplink options for connecting to fiber backbones or upstream switches.

L2+ capabilities such as static routing, DHCP service, ACL, storm control, DoS defense, DHCP Snooping, SNMP, and RMON help improve traffic handling, network visibility, and security in larger deployments.

Installation Notes

This Cloud L2+ managed PoE switch is suitable for high-density PoE access and aggregation deployments. PoE planning should account for the total 397W power budget and the 30W maximum output available on ports 1-24, while uplink planning should account for SFP and combo SFP port usage.
