Wi-Tek - WI-POE51-48V-V2 - 30W PoE PoE Injector
Part number:
Price:
Highlight Features
● 1*10/100/1000Mbps 802.3af/at PoE+ port
● 1*10/100/1000Mbps Ethernet input port
● AC IN 100-240V
● Plug and play, no configuration
| Model | WI-POE51-48V |
| Hardware Specifications | |
| Hardware Version | V2 |
| Interfaces | |
| Interfaces | 1 × 100Mbps/1000Mbps RJ45 LAN port 1 × 100Mbps/1000Mbps PoE port |
| PoE | |
| PoE Standard | 802.3af/at |
| PoE Output Power | 48V 0.5A Max |
| PoE Pin Assignment | 1/2(+), 3/6(-) |
| Power Supply | |
| Input Power | AC 100 ~ 240V 50/60Hz 0.3A Max |
| Physical Characteristics | |
| LED Indicators | Power Blinking: Abnormal power reception On: the device power on is normal Off: the device is powered off or failed |
| Fan Quantity | Fanless |
| Injector Dimension | 114 × 48 × 30 mm |
| Package Dimension | 200 × 132 × 42 mm |
| Weight | Net Weight: 0.12 kg Package Weight: 0.26 kg |
| Installation | Desktop |
| Reliability | |
| Surge Immunity | IEC 61000-4-5 Common mode 3kV Differential mode 2kV |
| ESD Protection | IEC 61000-4-2 Contact discharge 6kV Air discharge 8kV |
| Environmental | |
| Operating Temperature | -10℃ to 55℃ (14℉ to 131℉) |
| Operating Humidity | 5% ~ 90% RH no condensation |
| Storage Temperature | -40℃ to 75℃ (-40℉ to 167℉) |
| Storage Humidity | 5%~95% RH no condensation |
| Others | |
| Certification | CE, FCC, RoHS, UKCA, RCM |
