Wi-Tek - WI-PS210GS - 8FE + 2GE Hi-iPoE switch, 250m, 95W

Product Overview

The Wi-Tek WI-PS210GS V2 is an unmanaged Hi-PoE switch designed for small CCTV and network access deployments. It provides eight 100Mbps RJ45 PoE ports, two Gigabit RJ45 uplink ports, 802.3af/at PoE support, Extend Mode for long-range PoE transmission up to 250m, and a total PoE power budget of up to 95W.

Key Configuration

Model: WI-PS210GS V2 | Product Type: 8FE + 2GE Hi-PoE Switch | PoE Ports: 8 x 100Mbps RJ45 | Uplink Ports: 2 x Gigabit RJ45 | PoE Ports: 1-8 | PoE Standard: IEEE 802.3af/at | PoE Budget: Up to 95W | Long Range: Up to 250m | Switching Capacity: 5.6Gbps | Packet Forwarding Rate: 4.17Gbps | MAC Address Table: 2K | Dimensions: 200 x 118 x 44mm | Power Supply: Internal adapter, DC52V 1.25A output | Operating Temperature: 0°C to 40°C | Operating Humidity: 10% to 90%

Key Features

 · Provides eight 100Mbps RJ45 PoE ports for powered network devices

 · Includes two Gigabit RJ45 uplink ports for network connectivity

 · PoE ports 1-8 support IEEE 802.3af/at powered devices

 · Total PoE power budget of up to 95W supports multiple PoE endpoints

 · Extend Mode supports long-range PoE transmission up to 250m

 · 5.6Gbps switching capacity supports efficient local traffic handling

 · 4.17Gbps packet forwarding rate supports stable data transmission

 · 2K MAC address table supports small network deployments

 · Internal power adapter provides DC52V 1.25A output

 · Compact 200 x 118 x 44mm housing supports easy placement

Technical Context

The WI-PS210GS V2 is intended for IP camera, access point, and small network deployments where several 100Mbps PoE devices need to connect back to a Gigabit uplink. Its eight PoE ports provide power and data over Ethernet, while the two Gigabit uplinks help connect the switch to an NVR, router, or upstream network switch.

Extend Mode is useful for surveillance installations where cameras are located farther from the switch, supporting PoE transmission up to 250m when configured for long-range operation.

Installation Notes

The WI-PS210GS V2 is suitable for indoor PoE access installations operating within 0°C to 40°C and 10% to 90% humidity. PoE planning should account for the total 95W power budget and the long-range requirements of any camera connected in Extend Mode.
