Cyber Power - PR2200RTXL2UACN - 2200VA/2200W, Sine Wave, 2U, NEMA L5-30P, 10 Ft Cord, PowerPanel Business Edition software, Built-in Cloud, Accepts EBM BP48VP2U03, Pre-installed RMCARD205
2200VA/2200W, Sine Wave, 2U, NEMA L5-30P, 10 Ft Cord, 8 NEMA 5-20R, USB, Serial, SNMP, Relay, EPO, PowerPanel Business Edition software, Built-in Cloud, Accepts EBM BP48VP2U03, Pre-installed RMCARD205, 3 Yr Warranty. The PR2200RTXL2UACN is a Smart App Sinewave rack/tower convertible UPS with line-interactive topology, surge protection, and battery backup. CyberPower’s Smart App Sinewave series creates a sine wave output devoid of power gaps which could cause unexpected shutdowns of sensitive equipment.
The Smart App Sinewave PR2200RTXL2UACN improves battery life through battery equalization technology and Automatic Voltage Regulation (AVR), which corrects minor power fluctuations without switching to battery power. The enhanced chassis design with an easy-to-access toolless front panel, captive screws for battery panel access, and color-coded rear panel make battery changes and installations simple and fast. The PR2200RTXL2UACN also has an innovative LCD panel that rotates 90°, tilts for a better viewing angle, and provides information on 47 different settings including UPS stats, UPS setup and control management, and testing options.
This model accepts the BP48VP2U03 Extended Battery Module (EBM) for expanded runtime during power outages and includes built-in cloud monitoring and pre-installed RMCARD205 network management card for remote management and control via a standard web browser or network management system.
TYPICAL APPLICATIONS:
- Department Servers
- Storage Devices
- VoIP Installations
- Network Devices
- Corporate Servers
- Telecom Installations
FEATURES:
- Capacity: 2200 VA / 2200 W
- Topology: Line Interactive
- Waveform: Sine Wave
- Output: 100-120 VAC +/- 5%
- Runtime (half/full): 16.1 minutes / 6.3 minutes
- Plug type & cord: NEMA L5-30P, 10-ft. cord
- Outlets: 8 surge + battery backup
- Outlet types: 8 × NEMA 5-20R
- Communication: USB, Serial, SNMP, Relay, EPO, Cloud
- Management software: PowerPanel® Business
- Remote management: Yes, pre-installed RMCARD205 and built-in cloud
- Warranty: Three-Year
- Connected Equipment Guarantee: $400,000
- ENERGY STAR® certified: Yes
| OUPUT | |
| Automatic Voltage Regulation | Double Boost, Single Buck |
| On Battery Frequency | 50 Hz - 60 Hz +/- 1% |
| On Battery Voltage | 100/110/120 VAC +/- 5% |
| On Battery Waveform | Sine Wave |
| Outlet Type | 8 x NEMA 5-20R |
| Outlets - Battery & Surge Protected | 8 |
| Outlets - Critical Load | 4 |
| Outlets - Total | 8 |
| Overload Protection | Internal Circuitry Limiting Circuit Breaker Protected |
| VA | 2200 VA |
| BATTERY | |
| Battery Size | 12 V / 5.7 Ah |
| Battery Type | Sealed Lead-Acid Battery |
| Extended Battery Module | BP48VP2U03 |
| Hot-Swappable | Yes |
| Runtime at Full Load | 6.3 min. |
| Typical Recharge Time | 3 Hours (0% to 90% charged) |
| SURGE PROTECTION & FILTERING | |
| EMI/RFI Filtration | Yes |
| Surge Suppression | 2430 J |
| MANAGEMENT & COMMUNICATIONS | |
| Audible Alarms | Battery Mode Low Battery Overload Overcharge Overheat |
| LCD | Multifunction LCD |
| Management Cable | USB Cable EPO Cable |
| Software (Free Download) | PowerPanel® Business |
| Color | Black |
| Material of Construction | Metal |
| DIMENSIONS | |
Dimensions - Width/Height/Depth (cm) | 43.43 x 8.64 x 62.99 cm |
Dimensions - Width/Height/Depth (mm) | 434 x 86 x 630 mm |
Dimensions - Width/Height/Depth (in.) | 17.1 x 3.4 x 24.8 in |
| Weight (kg) | 42.18 kg |
| Weight (lbs.) | 93.0 lbs. |
| SHIPPING DIMENSIONS | |
Shipping Dimensions - Width/Height/Depth (cm) | 57.4 x 27.43 x 76.45 cm |
Shipping Dimensions - Width/Height/Depth (mm) | 574.04 x 274.32 x 764.54 mm |
Shipping Dimensions - Width/Height/Depth (in.) | 22.6 x 10.8 x 30.1 in |
| Shipping Weight (kg) | 50.21 kg |
| Shipping Weight (lbs.) | 110.7 lbs. |
| ENVIRONMENTAL | |
| Audible noise at 1m from surface of unit | 57.5 dBA |
| Online Thermal Dissipation | 135 BTU/hr |
| Operating Elevation | 0 - 9,843 ft (0 - 3,000 m) |
| Operating Relative Humidity | 0 - 95 % (non-condensing) |
| Operating Temperature | 32 - 104 °F (0 - 40 °C) |
| Storage Elevation | 0 - 49,213 ft (0 - 14,999 m) |
| Storage Relative Humidity | 0 - 95 % (non-condensing) |
| Storage Temperature | 5 - 113 °F (-15 - 45 °C) |
| CERTIFICATIONS | |
| Environmental | RoHS Compliant |
| Safety | UL1778 CSA C22.2 No 107.3 FCC Class A VCCI |
| WARRANTY | |
| CEG Amount | $400,000 |
| Connected Equipment Guarantee | Lifetime |
| Extended Warranty Option | WEXT5YR-U4B |
| Product Warranty | 3-Year Limited |
| GENERAL | |
| Active PFC Compatible | Yes |
| Energy Saving | GreenPower UPS™ Bypass Technology |
| ENERGY STAR® Certified | Yes |
| UPS Topology | Line Interactive |
| INPUT | |
| Adjustable Voltage Range | 70 - 155 VAC |
| Circuit Breaker | 30A |
| INPUT - CONT. | |
| Cord Length | 10 ft. (3.0 m) |
| Input Frequency Range | 47 Hz - 63 Hz |
| Input Plug Type | NEMA L5-30P |
| Input Voltage | 100 - 120 VAC |
| Input Voltage Range | 75 - 155 VAC |
| Nominal Input Voltage | 120 VAC |
| Plug Style | Straight (Twist Lock) |
