Hikvision - DS-AJ7824D - CVR EX 24HDD 2 Controllers
Part number:
DS-AJ7824D
Price:
24-slot SAS Enclosure (dual controller). DS-AJ7824D storage enclosure is a storage product designed for large-scale video security project. It can expand storage space quickly, which is helpful in reducing cost. It also provides highly reliable functions and feature, like hot swapping, redundant power supply, and redundant fan.
Features:
- Dual controller, enterprise-class SAS enclosure for expanding storage while reducing costs
- Supports hot swap HDD, redundant power supply, redundant fan
- Mini SAS 3.0 able to transmit four times faster than 12G
- Supports cascading expansion and SAS HDD interfaces
Controller | Number of controller | 2 |
| SAS interface (upper-level) | 2 (12 Gbps) | |
| SAS interface (lower-level) | 1 (12 Gbps) | |
| Number of HDD interface | 24 | |
| HDD interface Type | SAS | |
| HDD hot swapping | Supported | |
| Power supply | Redundant (1+1) | |
| Applicable model | DS-A82024D | |
General | Chassis | 4U |
| Dimensions (W × H × D) | 484 x 174 x 760 mm (19.1 x 6.9 x 29.9 inch) | |
| Wight (without HDD) | 40 kg (88.2 lb) | |
| Consumption (with max. HDD) | ≤ 550 W | |
| Working temperature | 5 °C to 40 °C (41°F to 104 °F) | |
| Storage temperature | -20 °C to +70 °C (-4°F to +158 °F) | |
| Working humidity | 20% to 80% (non-condensing/frozen) | |
| Storage humidity | 5% to 90%RH (non-condensing/frozen) |
