Hikvision - DS-D60E-B - Digital Signage Box
Part number:
DS-D60E-B
Price:

Digital Signage Box



Features:

  • Variable Materials Supports static and dynamic materials, including the application, pictures, audio, video, PDF, streaming media, webpage, live video, third-party data, etc.
  • Flexible Program Schedule Supports free schedule and district display of multiple materials. Supports variable display modes: display by day, display by week, custom display, etc.
  • Centralized Management Remotely control and manage one or more screens, such as timed startup/shutdown, timed brightness/volume, and screenshot previewing.
  • Organization Feature 5-level organization is available for managing materials, programs, terminals, and users.
  • Multilevel User Permission Supports creating custom users, and allocating permission for users according to user level.
  • Multiple Security Safeguards 3-level check of materials, programs, and schedules to prevent mistake release. Screensaver to secure safe for broadcast contents. Encryption of data storage and transmission to avoid data tampering.
  • Arbitrary Direction Remote Control The remote control, adopting wireless communication in 433 MHz, can control the information distribution box in arbitrary direction.
CategorySpecification
Resolution1920 × 1080@30/50/60 Hz, 1280 × 720@30/50/60 Hz, 3840 × 2160@30/50/60 Hz
Operation SystemAndroid 8.1.0
CPUCortex-A17, 4-core, 1.6 GHz
Memory2 GB
Storage16 GB (EMMC)
Video & Audio InputAUDIO IN × 1
Video & Audio OutputAUDIO OUT × 1, HDMI OUT × 1
Network InterfaceLAN × 1, Wi-Fi
Data TransmissionUSB 2.0 × 2, Bluetooth 4.0
Power Supply12 VAC, 2 A
Standby Consumption≤ 1 W
Working Temperature0 °C to 40 °C (32 °F to 104 °F)
Product Dimensions145 mm × 145 mm × 31.89 mm (5.7" × 5.7" × 1.3")
Working Humidity10% to 90%
Package Dimensions188 mm × 176 mm × 101 mm (7.4" × 6.9" × 4.0")
Net Weight0.6 kg (1.3 lb.)
Gross Weight0.65 kg (1.4 lb.)
Packing ListPower Adaptor × 1, Remote Control × 1
Supported Media FormatsDAT, MPG, VOB, TS, AVI, MKV, MP4, MOV, 3GP, FLV, WEBM, WMV, ASF; MP1, MP2, MP3, WMA, WAV, OGG, OGA, FLAC, ACC, M4A, XMF, MXMF, RTTTL, RTX, OTA, IMY; JPG, JPEG, BMP, GIF, PNG
