Digital Watchdog - DW-BJAiHDX7132T - Blackjack AI DX7, Windows OS on SSD, Hosting DW Ai Software Deep Learning, 4 DW Spectrum recording licenses and 4 Ai Server licenses pre-installed, 10 analytic streams, 480Mbps throughput, Intel i7, 16GB RAM, 32TB
Part number:
DW-BJAiHDX7132T
Price:

Blackjack AI DX7, Windows OS on SSD, Hosting DW Ai Software Deep Learning, 4 DW Spectrum recording licenses and 4 Ai Server licenses pre-installed, 10 analytic streams, 480Mbps throughput, Intel i7, 16GB RAM, 32TB storage, 1x mini Display Port, NDAA, TAA, 5 Year Limited Warranty.



Server-Side Analytics for Non-Analytic Cameras
Bring classified object detection (bicycles, cars, counters, forklifts, motorcycles, persons, trucks, unclassified and vans) to your existing non-analytic cameras



All-in-One Device
Achieve lower deployment cost with a single device that performs as an NVR and an analytics server



Ai Analytics and deep learning
DW Ai solutions include all the Intelligent Video Analytics and advanced Video Content Analysis detection capabilities of the Ai engine In addition, Ai servers empower users with deep learning objects and people tracking and color filters



Deep Learning
DW’s Ai intelligent algorithms offer deep learning with better object detection and identification of environmental elements The result is a substantial reduction in false alarms for control room operators and security personnel Allowing only valid events to filter through increases efficiency and productivity, and reduces unnecessary costs



Easy setup (no manual analytics calibration)
DW’s Ai allows operators to choose what to detect and where; with a user-friendly and straightforward UI, users can set up multiple scenarios specific to their monitoring needs without complex calibration



Reduce false alarms
DW’s Ai accurately categorizes moving objects and people, distinguishing them from environmental items such as spiders, shaking shadows and moving lights The result is a reduction in false alarm rates, saving storage and enabling more efficient monitoring



Max throughput and IP camera support
This Blackjack server can record and manage single-sensor and multi-sensor IP cameras of any resolution up to of 480Mbps throughput.



Designed and commissioned in the USA
All DW recorders, workstations and NAS devices are designed, assembled and inspected in our California facility Each product undergoes multiple levels of quality control to guarantee the highest quality and performance



Features:

  • Hosting DW Ai software deep learning and color filter
  • Server-side analytics for non-analytic cameras, Hailo AI Processor
  • Deep learning classifiers
  • A single device for NVR and Analytics server for lower deployment cost
  • Record and manage single- and multi-sensor IP cameras of any resolution up to 480Mbps throughput
  • Up to 10 analytic streams
  • Supports all ONVIF conformant IP cameras
  • Up to 40TB internal storage
  • 12th Gen Intel Core i7 processor
  • True HD and Display Port, for system configuration
  • 1 x 1Gb Ethernet, 1x 2.5Gb Ethernet ports
  • Windows 11 IoT Enterprise LTSC on separate SSD
  • Hosting DW Spectrum for setup, configuration, monitoring and recording
  • One-time recording license charge, fully transferable between cameras and encoders
  • One (1) 4-channel license included (DW-SPECTRUMLSC004).
  • One (1) 4-channel DW Ai Server license included (DW-DWAiSLSC004)
  • No annual maintenance fees
  • Dual stream recording
  • USB mouse and keyboard included
  • Designed, assembled and tested in the U.S.A.
  • NDAA/TAA compliant for federal and government projects
  • 5 Years limited warranty
Specifications
Hardware
AI ProcessorHailo 8 Processor
CPUIntel i7 processor
Local Video Outputs1x DisplayPort output, 1x True HD output, 1 display output at a time, For initial system configuration
Memory16GB
Video CardOnboard Intel Xe Graphics
Video CompressionH.264, H.265
OS on SSD480GB SSD
Max throughput (Mbps)    480Mbps
Storage
Raw internal storage options008TB  012TB  016TB  020TB  024TB  032TB  040TB
RAID OptionsNo RAID
Max HDD Bay2 x SATA HDD
Maximum Storage8TB (DW-BJAiHDX7108T), 12TB (DW-BJAiHDX7112T), 16TB (DW-BJAiHDX7116T), 20TB (DW-BJAiHDX7120T), 24TB (DW-BJAiHDX7124T), 32TB (DW-BJAiHDX7132T), 40TB (DW-BJAiHDX7140T)
VMS features
Max # of analytic streams (secondary)Up to 10
Performance featuresA single device for NVR and Analytics server for lower deployment cost, Deep learning classifiers and logical rules engine, Server-side analytics for non-analytic cameras
Playback FunctionsCalendar, Event search, Smart motion search, Thumbnail search, Timeline
PTZ controlONVIF
Recording ModesContinuous, Motion + low res always, Motion + Object, Motion + Object + Low res, Motion detection, Object + Low res, Object only
System OperationGraphical user interface (GUI), Remote via DW Spectrum, USB mouse (included)
Network
Ethernet Ports1x 1G Ethernet (RJ45), 1x 2.5Gb Ethernet (RJ45)
Pre-loaded VMS softwareDW Spectrum®
Remote ClientCross-platform - Windows, Linux Ubuntu and Mac, DW Mobile Plus, DW Spectrum Mobile App
Electrical
Power Consumption300W, A UPS is recommended
General
AccessoriesKeyboard, Mouse
Ai Configuration Tool supported OSCross-platform - Windows and Linux Ubuntu
Included DW Ai Server Licenses4 channel (DW-DWAiSLSC004)
Included IP licenses4 (DW-SPECTRUMLSC004)
Operating Temperature and Humidity20 ~ 90% RH, 41 ~ 104 °F (5~40 °C)
Preloaded Analytic softwareDW Ai Server
Recorder Dimensions (H X W X D)Desktop: 3.88” x 13.1” x 15.8” (98.5 x 334 x 402 mm)
Recording Licenses (Optional. Sold Separately)DW-SPCP04LSC004 - Four (4) DW Spectrum Analog Encoder Licenses DW-SPCP16LSC016 - Sixteen (16) DW Spectrum Analog Encoder Licenses, DW-SPECTRUMLSC001 - Single DW Spectrum Recording License, DW-SPECTRUMLSC004 - Four (4) DW Spectrum Recording Licenses, DW-SPECTRUMLSC010 - Ten (10) DW Spectrum Recording Licenses DW-SPECTRUMLSC020 - Twenty (20) DW Spectrum Recording Licenses DW-SPECTRUMLSC050 - Fifty (50) DW Spectrum Recording Licenses DW-SPECTRUMLSC100 - One hundred (100) DW Spectrum Recording Licenses, DW-SPIOLSC001 - Single DW Spectrum I/O Module License, DW-SPVWALL1X2 - Single DW Spectrum Video Wall License, Lifetime upgrades are included with no annual renewal fees.
USB interfaceYes
Warranty5 Year Limited Warranty
Weight (barebone, HDD not included)15.65 lbs (7.09 kg)
CertificationNDAA  ONVIF Conformant  TAA Compliance
Form FactorSlim Desktop
