Digital Watchdog - DWC-MB62DiVTW - MEGApix Weather Resistant Bullet, 2.1 Megapixel ,1920x1080 @ 30fps, 2.7-13.5mm Varifocal P-Iris Lens, 100ft Smart IR, D-WDR, 3D-DNR, True D&N, Triple Codecs (H.265, H.264, MJPEG) with Simultaneous Streaming, PoE Cla
Part number:
DWC-MB62DiVTW
Price:

This MEGApix IP camera provides 2.1MP/1080p resolution at realtime 30fps. It includes a 2.7~13.5mm vari-focal lens and simultaneous H.265/H.264/MJPEG codec support, all in an IP66 weather-resistant bullet housing. All MEGApix® cameras are ONVIF conformant, assuring their successful integration with any open platform solution on the market.



Smart 3D DNR (digital noise reduction)

Use DW’s exclusive noise reduction technology to produce clearer color and monochromatic video in low light without adding visual lag or ghost effects.



H.265 codec support

High-Efficiency video codec standards deliver 25% to 50% better data compression while maintaining video quality.



Smart IR

Smart IR adjusts the image for IR cameras to prevent excessive illumination on objects that are in the front of the scene and offers a clear image in B/W without any loss of detail.



Features:

  • 2.1MP/1080p 1/2.9" image sensor at real-time 30fps
  • 2.7~13.5mm vari-focal lens
  • Digital Wide Dynamic Range (D-WDR)
  • Triple codecs (H.265, H.264, MJPEG) with simultaneous streaming
  • 100' Smart IR with intelligent camera sync
  • Smart DNR 3D digital noise reduction
  • Electronic day/night
  • Programmable privacy zones
  • Auto gain control (AGC)
  • Backlight compensation (BLC)
  • Auto white balance (AWB)
  • Motion detection
  • Web server built-in
  • PoE class 3 and DC12V
  • Waterproof cabling
  • UL listed
  • NDAA compliant
  • IP66 environmental-rated dust-tight and water-resistant
  • 5 year warranty
Maximum resolution2.1MP/1080p
Minimum Scene Illumination in color0.0 lux (B/W)
0.16 lux (color)
Lens
Horizontal Field of View (HFOV)89.6° ~ 27°
Illumination Distance90' range Smart IR™
Lens TypeVari-focal Lens
Vertical Field of View (VFOV)49.9° ~ 15.2°
Operational
3D digital noise reductionSmart DNR™ 3D Digital Noise Reduction
Auto gain controlAuto
Day and nightAuto day/night
Day (color)
Night (B/W)
Mirror/flipYes
Motion DetectionYes
Operational NotificationsEmail
FTP server
SD card recording
SharpnessYes
White BalanceYes
Network
Network Web ViewerGoogle Chrome® browser
Linux® OS
Mac® OS
Microsoft Edge® browser
Mozilla Firefox® browser
Safari® browser
Windows OS
ProtocolZeroconf (AutoIP)
Security802.1x
Digest authentication (ID/PW)
HTTPS (TLS)
IP filtering
Video Compression TypeH.264
H.265
MJPEG
Video Management SoftwareDW Spectrum®
Environmental
ComplianceCEFCCNDAA CompUL Listing
Environmental Operating Temperature-4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional)Optional. Sold separately
Mechanical
Camera Dimensions (H X W X D)*Dimensions based on the position of the sun shield cover
HousingBullet
Housing ColorWhite
IP ratingWeather Resistant (IP66)
MaterialsAluminum die-casting
Electrical
American wire gauge (AWG)Cable type #18
Power RequirementsAdapter not included
PoE
General
Warranty5 Year Warranty
