Multi-Target-Type Detection
Embedded deep learning algorithms detect and capture the face and human body in specified regions and outputs features such as gender, age, and top color. It supports a structurized modeling of the face and human body to achieve structurized data collection.
Queue Management
Embedded deep learning based algorithms detect queued people number and waiting times. The body feature detection algorithm filters out wrong targets and increases detection accuracy.
Metadata
Metadata uses individual application data instances or the data content. Metadata can be used for third-party application development.
Smooth Streaming
Smooth streaming improves video quality in different network conditions. For example, in poor network conditions, adapting to the detected realtime network condition, streaming bit rate and resolution are automatically adjusted to avoid mosaic and lower latency in live view; in multiplayer network conditions, the camera transmits redundant data for self-error correcting in back-end device to solve mosaic problems because of packet loss and error rate.
Anti-Corrosion Coating
The camera adopts high weatherproof and wearproof molding powder that confirms to AAMA2604-02 and Qualicoat (Class2) specifications, and uses two-layer special
Attribute-Based People Counting
Embedded deep learning algorithms integrate multiple intelligences. They count people, sample face features, and identify people who pass repeatedly over a period of time. They count persons and send a face alarm for entrance control and people counting.
Hard Hat Detection
Embedded deep learning algorithms detect persons in a specified region. They detect if the person is wearing a hard hat and captures the person’s head and sends an alarm if not.
Features:
- High quality imaging with 12 MP resolution
- Clear imaging against strong back light due to DWDR technology
- Efficient H.265+ compression technology to save bandwidth and storage
- Advanced streaming technology that enables smooth live view and data self-correcting in poor network
- 5 streams and up to 5 custom streams to meet a wide variety of applications
- Water and dust resistant (IP67) and vandal proof (IK10)
- Anti-IR reflection bubble guarantees image quality
| Specification | iDS-2CD75C5G0-IZHSY 2.8–12 mm |
| Camera | |
| Image Sensor | 1/1.7" progressive scan CMOS |
| Minimum Illumination (AGC on) | Color @ ¦/1.2 0.009 lux B/W @ ¦/1.2 0.0009 lux Color @ ¦/2.5 0.039 lux B/W @ ¦/2.5 0.0039 lux |
| Shutter Speed | 1 s to 1/100,000 s |
| Slow Shutter | Yes |
| Wide Dynamic Range | Digital WDR |
| Day/Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Power-Off Memory | Yes |
| Flash Memory | 8 GB |
| RAM | 2 GB |
| Lens | |
| Focus | Auto, semi-auto, manual |
| Lens | 2.8 mm to 12 mm |
| Horizontal | 96° to 46.2° |
| FOV Vertical | 69.2° to 27.2° |
| Diagonal | 131° to 45.2° |
| Aperture | ¦/1.2 to ¦/2.5 |
| Lens Mount | Integrated |
| Blue Glass Module | Blue glass module to reduce ghost phenomenon |
| P-Iris | Yes |
| Illuminator | |
| IR Range | 98 ft (30 m) |
| Wavelength | 850 nm |
| Smart Supplement Light | Yes |
| Video | |
| Maximum Resolution | 4000 × 3000 |
| Main Stream | 50 Hz: 25 fps (4096 × 2160,3840 × 2160,3072 × 1728,2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (4096 × 2160,3840 × 2160,3072 × 1728,2560 × 1440, 1920 × 1080, 1280 × 720) 50 Hz: 20 fps (4000 × 3000) 60 Hz: 20 fps (4000 × 3000) |
| Sub Stream | 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Third Stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Fourth Stream | 50Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Fifth Stream | 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Custom Stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264 Sub-stream/third stream/fourth stream/fifth stream/custom stream:H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| H.264+ | Main Stream supports |
| H.265+ | Main Stream supports |
| Bit Rate Control | CBR/VBR |
| Stream Type | Main stream/sub-stream/third stream/fourth stream/fifth stream/custom stream |
| Scalable Video Coding (SVC) | H.265 and H.264 support |
| Region of Interest (ROI) | 4 fixed regions for each stream |
| Audio | |
| Environment Noise Filtering | Yes |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3 |
| Audio Bit Rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32–192 Kbps (MP2L2)/32 Kbps (PCM)/8–320 Kbps (MP3) |
| Audio Type | Mono sound |
| Network | |
| Simultaneous Live View | Up to 20 channels |
| API | ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1x, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Smooth Streaming | Yes |
| User/Host | Up to 32 users. 3 user levels: administrator, operator, and user |
| Security | Password protection, complicated password, HTTPS encryption, 802.1x authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE, digest authentication for ONVIF, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2 |
| Network Storage | MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR); with high-end Hikvision memory card, memory card encryption and health detection supported |
| Client | iVMS-4200, Hik-Connect, HikCentral |
| Web Browser | Plug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local service: Chrome 41.0+, Firefox 30.0+ |
| Image | |
| Smart IR | Camera IR LEDs should support Smart IR function to automatically adjust power to avoid image overexposure |
| Day/Night Switch | Day, Night, Auto, Schedule, Triggered by Alarm In |
| Target Cropping | Yes |
| Picture Overlay | Logo picture can be overlaid on video with 128 × 128 24-bit bmp format |
| Image Enhancement | BLC, HLC, 3D DNR, Defog, EIS, Distortion Correction |
| Image Parameters Switch | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or Web browser |
| SNR | ≥52 dB |
| Interface | |
| Alarm | 1 input, 1 output (maximum 24 VDC, 1 A) |
| Audio | 1 input (line in), 3.5 mm connector, maximum input amplitude: 3.3 vpp, input impedance: 4.7K Ω, interface type: non-equilibrium; 1 output (line out), 3.5 mm connector, maximum output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound, 1 built-in microphone |
| RS-485 | 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| Video Output | 1 Vp-p composite output (75 Ω/CVBS) (only for debug) |
| On-Board Storage | Built-in microSD/SDHC/SDXC slot, up to 256 GB |
| Hardware Reset | Yes |
| Communication Interface | 1 RJ-45 10M/100M/1000M self-adaptive Ethernet port |
| Power Output | 12 VDC, maximum 200 mA (supported by all power supply types) |
| Smart Features | |
| Basic Event | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Smart Event | Line crossing detection, up to 4 lines configurable Intrusion detection, up to 4 regions configurable region entrance detection, up to 4 regions configurable region exiting detection, up to 4 regions configurable; Unattended baggage detection, up to 4 regions configurable object removal detection, up to 4 regions configurable; scene change detection, audio exception detection, defocus detection |
| Counting | Yes |
| Intelligent (Deep Learning Algorithm) | |
| Multi-Target Detection | Simultaneous detection of human body and face, gets 8 face features and 13 human body features |
| Attribute-Based People Counting | Entering/exiting counting (track 30 targets simultaneously); identifies people who pass repeatedly over a period of time |
| Hard Hat Detection | Detects up to 30 human targets simultaneously, supports up to 4 shield regions |
| Queue Management | Detects queuing-up people number and waiting time of each person, generates reports to compare the efficiency of different queuing-ups and displays changing status of one queue, raw data export for further analysis |
| Premier Protection | Line crossing, intrusion, region entrance, region exiting, alarm trigger by specified target types (human, vehicle), filter out mistaken alarm caused by target types such as leaf, light, animal, flag, etc. |
| General | |
| Linkage Method | Upload to FTP/NAS/memory card, notify surveillance center, send e-mail, trigger alarm output, trigger recording, trigger capture; trigger recording: memory card, network storage, pre-record and post-record trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, e-mail; trigger notification: HTTP, ISAPI, alarm output, e-mail |
| Online Upgrade | Yes |
| Dual Backup | Yes |
| Web Client Language | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil),Ukrainian |
General Function | Anti-flicker, 5 streams and up to 5 custom streams, EPTZ, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter |
| Software Reset | Yes |
| Storage Conditions | -30° to 60° C (-22° to 140° F), humidity 95% or less (non-condensing) |
| Startup/Operating Conditions | -30° to 60° C (-22° to 140° F) |
| Power Supply | |
| 12 VDC ±20% | Three-core terminal block, reverse polarity protection |
| 24 VAC ±20% | Three-core terminal block, reverse polarity protection |
| PoE | 802.3at, Type 2, Class 4 12 VDC, 1.16 A, maximum 13.9 W |
| Power Consumption, Current | |
| With Extra Load* | PoE (802.3at, 42.5 V to 57 V), 0.33 A to 0.25 A, class 4 (*extra load is extra device connected to and powered by camera) |
| Without Extra Load |
PoE (802.3at, 42.5 V to 57 V), 0.3 A to 0.22 A, class 4 |
| Power Interface | Three-core terminal block Camera Material Aluminum alloy body |
Camera Dimension | Ø140.5 mm × 122.6 mm (Ø5.5" × 4.8") |
Package Dimension | 244 mm × 174 mm × 173 mm (9.6" × 6.9" × 6.8") |
| Camera Weight | Approximately 1550 g (3.4 lb) |
| With Package Weight | Approximately 2206 g (4.9 lb) |
| Metadata | |
| Metadata | Metadata of intrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal, face capture and queue management |
| Approvals | |
| Class | Class B |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
Safety | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
| Environment | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection | IK10 (IEC 62262:2002) |
| Anti-Corrosion Protection | NEMA 4X (NEMA 250-2018) |
