Luxriot - LR1-3U-IPSVR1-48TB - 3U SERVER- 48TB (HOT_SWAP RAID6) 16 bay Hot Swap . Total of 15 x 4TB Drives
Part number:
LR1-3U-IPSVR1-48TB
Price:

3U SERVER- 48TB (HOT_SWAP RAID6) 16 bay Hot Swap . Total of 15 x 4TB Drives



Features:

  • COST EFFECTIVE RAID 6 Server with Enterprise Capabilities
  • 12Gbps Video Storage System
  • i7-7820X (8 Core) Series CPU
  • 16GB DDR4 Memory
  • Hardware RAID 6 With HOT SPARE
  • Includes NAND flash memory which offers Zero-Maintenance Cache Protection that eliminates Battery Backup Units (BBUs)
  • Hot-swappable rear fans put maintenance and management at ease.
  • INTEL SSD (SOLID STATE DRIVE) 240GB for OS and VMS
  • Includes a Hot spare drive
  • Network Video Recorder (NVR) Server for enterprise applications
  • Windows 10 Pro (64Bit)
  • From 20TB to 210TB internal storage or up to 630TB combined with our DAS units on single server.
  • Storage RAID 6 on Enterprise HDDs
  • Included additional gigabit NIC (total 2 x NICS)
  • Designed for robust high-performance computing
  • Redundant Power Supplies
  • Up to Unlimited client licenses
  • 3 year hardware warranty



Luxriot NVR ModelLuxriot 3U Single CPU RAID-6 32TB - 104TB Servers
Power Supply2 x 875W PS (Redundant) (110~240V)
Form Factor3U (32TB, 40TB, 48TB, 56TB, 64TB, 72TB, 80TB, 96TB & 104TB)
Cooling SystemBuilt-in 4x 80mm Hot Swap PWM Middle Fans
Operating SystemWindows 10 PRO (64 Bit) on dedicated 240GB SSD
NIC1 Internal + 1 PCI Gbit Ethernet 1000 Mbps LAN
DVD/CD RWExternal USB
StorageHot Swap 32TB-104TB Internal (Enterprise Drives SATA-6Gb/s at 7200 RPMs)
Raid Controller12Gb/s SAS 2.0 PCIe Interface Gen 3 host connection.
Chassis / Backplane16 Bay SATA / (1) 12Gb/s mini SAS Port
CPU(1) i9-10900X Dodeca-core (10 Core) 3.70 GHz Processor or higher
RAM32GB DDR4
Dimensions (Dx Wx H)660 x 432 x 132 (mm), 26” x 17” x 5.2”
Name
Description
Size
Downloads
File
Specifications
0.4mb
