SECO-LARM - AS-6111Q - Motion Entry Alert
Part number:
AS-6111Q
Price:

Motion Entry Alert, provides aproximately 4 seconds of audible alert (doorbell sound) when triggered, sensor range 10ft (3m), battery operated (3 AAA batteries, not included).



A simple to install audible motion alert for indoor use—no need for any wiring. The sensor is perfect as a door annunciator or for monitoring passageways in a wide range of home, office, and commercial applications.



Features:

  • Mount next to a door or other entry point to alert when someone enters or exits
  • Provides an audible alert (doorbell sound) when triggered
  • Sounds for approximately 4 seconds or for as long as the sensor detects changes in visible light
  • CDS sensor operates by detecting sudden changes in visible light*
  • Sensor range 10ft (3m)
  • Battery operated (3 AAA batteries, not included)
  • Designed for motion alerts only
  • Low current drain (0.05mA standby)



*IMPORTANT: AS-6111Q is designed to detect changes in visible light. Not for use in total darkness or facing a strong light.

Power Supply3x AAA Batteries (not included)
Current DrawStandby- Under 0.05mA@4.5VDC, Active- Under 85mA@4.5VDC
Low Battery IndicatorDevice will repeatedly activate
Input SignalCDS sensor
Output SignalDoorbell sound
Sensing Range10ft (3m) at 20”~40” (0.5~1m) height
MaterialABS plastic, white
Dimensions (With Bracket)3-3/8” x 3-3/8” x 2” (85 x 85 x 50 mm)
Weight3-oz. (84g)
