UNV - IPC-D124-APF28KM-A2 - 4MP Fixed Lens Dome 2.8mm Uniarch
• IP Bullet Camera - Uniarch
• 4 MP (2560x1440)
• Lens 4 mm
• microSD 512 GB
• White light 30 m
• WDR 120 dB
• Hunter Color with WISE-ISP technology
• PoE
• UMD (Ultra Motion Detection)
• IP67
• ONVIF Compatible
• Built-in microphone
• Minimum illumination 0.0003 lux
• Corridor mode 9:16
| Brand | Uniarch |
| Image Sensor | 1/3” Progressive Scan CMOS |
| Maximum Resolution | 4 Megapixel (2560x1440) |
| Main Stream Rate | 4 Mpx (2560x1440)@20fps 3 Mpx (2304x1296)@20fps 1080P (1920x1080)@30fps |
| Extra Stream Rate | 720p (1 ~ 20 FPS) |
| Compression | Ultra265/H.265/H.264 |
| Lens | 2.8 mm |
| Minimum Illumination | 0.02 Lux (Colour) |
| Infrared Range | 30 m |
| Image Improvements | DWDR, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR |
| Day / Night | Mechanical ICR filter |
| Internal Memory | No |
| Alarms | No |
| Audio | No |
| Network Interface | Ethernet 10/100 BaseT |
| Remote Access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Interoperability | ONVIF |
| Power | DC 12 V / 3.5 W PoE IEEE802.3af |
| Operating Temperature | -30º C ~ 60º C |
| Degree of Protection | Waterproof IP67 / Anti-vandal IK10 |
| Dimensions | 81 (H) x 109 (W) mm |
| Weight | 330 g |
This camera features a 4-megapixel image sensor using a 1/3-inch Progressive Scan CMOS, providing a maximum resolution of 2560 by 1440 pixels. It is equipped with a 2.8 millimeter fixed lens. The main video stream supports 4-megapixel resolution at 20 frames per second and other selectable resolutions, with compression using Ultra265, H.265, and H.264 codecs. It incorporates an infrared illuminator with a range of up to 30 meters.
The imaging features include Digital Wide Dynamic Range, Automatic Gain Control, 2D and 3D Digital Noise Reduction, Smart IR, and Region of Interest. The housing provides protection ratings of IP67 for dust and water resistance, along with IK10 for anti-vandalism. It is designed to operate in a temperature range from negative 30 degrees Celsius to 60 degrees Celsius. Power can be supplied via DC 12 volts or Power over Ethernet using the IEEE 802.3af standard, with a typical power consumption of 3.5 watts.
