UNV - NSW2100-17GT1GP1GC-POE-IN - Giga 16 Port Lite Cloud Managed PoE Switch
• Supports device configuration and management on the Web interface.
• Supports visiting the cloud by scanning the QR code. Allows to view the device status in real time on the APP.
• Supports PoE power supply . Allows to enable or disable PoE power supply for the powered device; allows up to 250m power supply using a standard network cable.
• Supports the extend mode for up to 250m communication range and 10Mbps auto-negotiation rate.
• Supports port priority. The priority port will be powered first when the PoE power supply is full.
• All metal casing, secure and reliable.
| Hardware | |
|---|---|
| Ports Type | 16x 10/100/1000Mbps PoE port (RJ45) 1x 10/100/1000Mbps port (RJ45) 1x Gigabit SFP 1x Gigabit Combo |
| Switching Capacity | 38 Gbps |
| Forwarding Performance | 28.272 Mpps |
| Packet Buffer | 4 Mbit |
| MAC Address Table | 8K |
| Priority Ports | 1 to 8 |
| Dimensions (W×D×H) | 440 x 189.8 x 44 mm |
| Power Supply | AC: 100V to 240V, 50/60Hz |
| PoE Standard | IEEE 802.3af, IEEE 802.3at |
| PoE Mode | Mode A (1236), Mode B (4578) |
| Max. PoE Power | Max capacity: 250W Maximum PoE power for single port: 30W |
| Max. Power Consumption | 265W |
| Cooling Fans | 1 |
| Weight | 2.11 kg |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Operating Humidity | 10% to 90% (noncondensing) |
| Indicator LEDs | Power: Off: Abnormal power input. Green: Normal power input. PoE: Off: No PoE power supply. Steady on: PoE power supply is normal. PoE-MAX: Off: POE power < 80% of spec. Steady on: POE power > 85% of spec. Link/Act: Off: Disconnected. On: Connected. Blinking: Transmitting data. |
| Software | |
| Ethernet | Supports full duplex, half duplex, and auto-negotiation working modes Supports enabling/disabling ports Supports port auto-negotiation rate Supports port priority flow control Supports port flow statistics |
| VLAN | Allows up to 32 VLANs with IDs from 1 to 4094 |
| MAC Address Management | Support static MAC, up to 32 entries |
| POE Management | Allows viewing PoE status and enabling/disabling PoE power supply via APP |
| Loop Detection | Loop Detection supported |
| Security | Supports port isolation |
| Maintenance | Supports N:1 port mirroring Supports device upgrade, factory settings restoration, configuration import, configuration export, and device restart via software |
| System | Allows viewing device name, current version, IP address, MAC address, DNS, etc. Allows editing and managing IP address and device name |
| Compliance | |
| NDAA Compliant | Support |
This is a 16-port managed PoE+ network switch. It provides 16x 10/100/1000Mbps PoE+ ports for connecting and powering devices like IP cameras, VoIP phones, or access points. Additional uplink options include one standard Gigabit Ethernet port, one Gigabit SFP port, and one Gigabit combo port. The switch supports the IEEE 802.3af (PoE) and 802.3at (PoE+) standards, delivering up to 30 watts per port with a total PoE budget of 250 watts.
Its switching capacity is 38 Gbps, with a forwarding performance of 28.272 million packets per second (Mpps). For network segmentation, it supports up to 32 VLANs. Device management, including PoE control, port configuration, and system monitoring, is performed via a dedicated software application. The switch is designed for indoor environments, operating within a temperature range of 0°C to 45°C. It is powered by a universal AC 100-240V input and consumes a maximum of 265 watts.
