SECO-LARM - SD-927PKC-NSQ - IR No-Touch Request-To-Exit Sensor with Spanish message. Green illuminated ring turns red and 3A relay is triggered when hand is passed in front of the plate. "SALIDA SIN TOCAR" printed on plate. ETL Listed. Conforms to UL
Part number:
SD-927PKC-NSQ
Price:
The ENFORCER Wave-To-Open Sensor uses IR technology to request egress from a protected area or activate a device with the simple wave of a hand. Since no-touch is required, this sensor is ideal for use in hospitals, clinics, labs, clean rooms (to reduce the risk of contamination), schools, factories, or offices.
Features:
- ETL UL294
- Dual voltage, 12~24 VAC/VDC
- Range adjustable from 2-3/8″~8″ (6~20 cm)
- Stainless steel single-gang plate
- 3A relay, adjustable from 0.5~30 sec, toggle, or as long as hand is near the sensor
- Quick connect screw-less terminal block
- LED illuminated sensor area for easy identification
- Selectable LED colors (turns from red to green or green to red) when activated
| Type | Wave-to-open Sensor |
| Current Draw | 120mA@12VDC |
| Sensing Range | Adjustable, 2-3/8″~8″ (6-20 cm) |
| Operating Voltage | 12~24 VAC/VDC |
| Reaction time | 10mS |
| LEDs – Red | Triggered |
| LEDs – Green | Standby |
| Relay Type | Form C (NO/NC/COM) 3A@24VDC |
| Output Time | Adjustable from 0.5~30 sec, toggle, or as long as hand is near the sensor |
| Switching Capacity | 3A@24VDC |
| Operating Temperature | -4°~131° F (-20°~55° C) |
| Dimensions | 4-1/2″ x 2-3/4″ x 1-5/16″ (115 x 70 x 33.5 mm) |
| Weight | 3oz (85g) |
