Hanwha - SKY-BR426p-0 - Wisenet SKY CMVR 426+ with 4TB
Part number:
SKY-BR426p-0
Price:
The Wisenet SKY Cloud Video Recorder (CVR) stores video and acts as a gateway from your premises to the Cloud Data Center where your video can also be stored by the Wisenet SKY Cloud VMS. It provides video storage, buffering, a secure connection, bandwidth management, and monitoring of cameras.
Features:
- CMVR 426+ with 4TB (Compact and Ruggedized Form Factor)
- 4MP: 20CH, Analytics: 15CH, up to 2 LPR cameras, 16TB HDD (35 days for 20 cameras @ 4MP), 2x HDMI
- This product is subject to the Wisenet SKY agreement.
- Supports up to 20 IP cameras @ 4MP.
- 16TB local storage capacity for ~35 days (20 cameras @ 4MP)
- Dual gigabit network
- Dual HDMI output
SYSTEM
| Maximum Cameras 1MP | / 30 |
| Maximum Cameras 4MP | / 25 |
| Maximum Cloud Analytics | / 10 |
| Hard Disk Drive | 4TB 15 days for 15 cameras @ 1MP / 10TB 20 days for 30 cameras @ 1MP |
| Network ports | Dual gigabit ethernet RJ-45 |
| Video output | 1x VGA, 1x DVI / 1x VGA, 1x HDMI, 1x DisplayPort |
| Indicator Lights | Power, disk activity |
| Operating System | Embedded Linux |
| USB Ports | x USB 3.0 (front) |
| Included accessories | Power cord, rack mount brackets |
| Rack Mount Brackets | Included |
| Mechanical | Form Factor | Rack mount or shelf/tabletop mount |
| Color / Material | Black / Metal | |
| Dimensions | 1U 16.81" x 9.88" x 1.75" (427mm x 251mm x 45mm) | |
| Weight | 8.95lb (4.06kg) / 9.76lb (4.42kg) | |
| Electrical | Power Supply | Internal, 65 W / 60 W |
| Power Input | ~ 240V AC | |
| Environmental | Operating Temperature | 32°F to 95°F (0°C to 35°C) |
| Operating Humidity | 0% to 70% RH, non-condensing | |
| Certification | FCC, UL, PSE, CE, CCC(S&E), REACH, RoHS, C-Tick, NDAA | |
Name
Description
Size
Downloads
File
A&E Specifications
0.8mb
File
Datasheet
1.1mb
