Wi-Tek - WI-AP219AX-Lite - Ultra-Fast Wi-Fi 6 Speeds: Simultaneous 600Mbps on 2.4 GHz and 2402Mbps on 5 GHz totals 3000Mbps Wi-Fi speeds (Ready at Aug middle)
Part number:
WI-AP219AX-Lite
Price:

WI-AP219AX-Lite is a high-performance Wi-Fi 6 AP suitable for indoor large-area Wi-Fi coverage scenarios. The device supports 802.3at PoE power for easy instal lation. WI-AP219AX-Lite compl ies with the 802.11a/b/g/n/ac/ax Wi-Fi protocol, supports 160MHz bandwidth and MU-MIMO dual-spatial streams, and provides a smoother wireless experience. It can operate at both 2.4GHz and 5GHz, providing high-speed wireless access up to 574Mbps in 2.4GHz, up to 2402Mbps in 5GHz, and up to 2976Mbps per AP in total, making it ideal for many wireless scenarios, especially in offices, shopping malls, hotels, service scenarios, etc.



Features:

  • Ultra-Fast Wi-Fi 6 Speeds: Simultaneous 600Mbps on 2.4 GHz and 2402Mbps on 5 GHz totals 3000Mbps Wi-Fi speeds
  • OFDMA and Uplink & Downlink MU-MIMO increase network capacity by up to 4× versus Wi-Fi 5 (802.11ac) in high-density environments to connect more devices simultaneously
  • Atheros chipset 512MB DDR3, 128MB Flash, 200mW High-Power,access 300users
  • 48V PoE Support,2 x 1Gbps Port, not include PoE adapter
  • Support QVLAN+SSID, Portal,AC controller Managed and  Cloud Managed
ModelWI-AP219AX-Lite
Hardware Specifications
Wireless StandardsIEEE 802.11ax/ac wave2/wave1/n/b/g/a
Operating Bands2.4GHz & 5GHz
Antenna2.4GHz:4dBi, 5GHz: 4dBi
Spatial Steams2.4GHz: 2x2 MIMO  5GHz: 2x2 MIMO
Signal RateUp to 574Mbps at 2.4GHz
Up to 2402Mbps at 5GHz
Receiver Sensitivity2.4GHz
802.11b: -85dBm@11M  -90dBm@1M
802.11g: -72dBm@54M  -90dBm@6M
802.11n HT20: -70dBm@MCS7  -87dBm@MCS0
802.11n HT40: -68dBm@MCS7  -85dBm@MCS0
802.11ax HE20: -60dBm@MCS11  -83dBm@MCS0
802.11ax HE40: -56dBm@MCS11  -83dBm@MCS0
5GHz
802.11a: -72dBm@54M  -92dBm@6M
802.11n HT20: -70dBm@MCS7  -90dBm@MCS0
802.11n HT40: -68dBm@MCS7  -88dBm@ MCS0
802.11ac VHT20: -70dBm@MCS8  -88dBm@ MCS0
802.11ac VHT40: -68dBm@MCS9  -88dBm@ MCS0
802.11ac VHT80: -58dBm@MCS9  -85dBm@ MCS0
802.11ax HE20: -62dBm@MCS11  -88dBm@MCS0
802.11ax HE40: -58dBm@MCS11  -86dBm@MCS0
802.11ax HE80: -55dBm@MCS11  -84dBm@MCS0
802.11ax HE160: -51dBm@MCS11  -82dBm@MCS0
Maximum Transmit Power≤23dbm
Interface(1)10/100/1000M Base-T Ethernet ports
Power Supply802.3at PoE Supported
Power Consumption< 16W
InstallationWall/Ceiling mounting
External Buttonsreset button (long press for 8 seconds to restore the factory default configuration)
Dimensions186mm * 186mm * 37mm
EnvironmentOperating temperature: -10°C to 55°C;
Storage temperature: -40°C to 70°C;
Humidity: 5%~95% (non-condensing)
Software Features
Operating ModeFit AP, Fat AP, Repeater, WISP
Wireless FunctionsUp to 16 SSIDs
Support SSID hiding, enable/disable wireless radio
Manual and automatic channel assignment
Manual and automatic bandwidth assignment
TxPower control
RoamingSupport Layer 2 roaming
Wireless SecurityCaptive portal authentication
Static blacklist and whitelist
Wireless isolation between clients
SSID to VLAN mapping
Support 802.1X
WPA/WPA2/PSK/WPA/WPA2-Enterprise/WPA3
Internet Connection TypeSupport static IP, DHCP, PPPoE Dial Up
ManagementSupport local management with web
Support centralized management with AC
Support remote management with Wi-Tek cloud platform
Platform ManagementAutomatic RF adjustment via the platform
FeaturesUnified configuration via the platform
 Unified monitoring via the platform
Name
Description
Size
Downloads
File
Datasheet
0.6mb
